The CTECHI Customized Wall-Mounted Hybrid Solar Inverter is a versatile and scalable solution for homeowners looking to harness the power of the sun. Available in 5kW, 10kW, and 15kW options, this inverter can be customized to meet the specific needs of your home's energy consumption.
Key Features and Benefits:
Customizable Power Output: Choose from 5kW, 10kW, or 15kW options to perfectly match your solar panel array size and energy demands.
Three-Phase Compatibility: Ideal for homes with three-phase power connections.
Hybrid Functionality: Works seamlessly with solar panels and battery storage systems (optional) for self-consumption and backup power.
Wall-Mounted Design: Compact and easy to install for efficient use of space.
Maximum Efficiency: Maximize your solar energy production for significant cost savings on your electricity bills.
Smart Monitoring: Monitor your energy production and consumption in real-time for informed energy management.
Peace of Mind: Enjoy backup power during outages and reduce reliance on the grid.
Take control of your energy future with the CTECHI Customized Wall-Mounted Hybrid Solar Inverter. Invest in clean, renewable energy and experience the benefits of solar power for your home.
Introducing CTECHI Three Phases Wall-Mounted Hybrid Inverter – Revolutionizing Energy Independence
Experience the pinnacle of energy independence with CTECHI's Series 3-phase hybrid inverter. Engineered for versatility and efficiency, this inverter series offers four power rates – 8kW, 10kW, 12kW, and 15kW – catering to both single-phase and three-phase loads with seamless compatibility.
Unmatched Compatibility:
Compatible with single-phase and three-phase loads, CTECHI's hybrid inverter supports 100% unbalanced load, ensuring reliable performance across diverse energy needs. Say goodbye to compatibility concerns and embrace the flexibility to power your home or business with confidence.
Optimized Efficiency:
With a maximum efficiency rating of up to 97.9%, CTECHI's three-phase hybrid inverters are engineered to maximize energy conversion, minimize waste and optimize output. Enjoy greater savings on your energy bills while reducing your environmental footprint.
Enhanced Energy Independence:
Designed to increase energy independence for homeowners, CTECHI's hybrid inverters empower you to take control of your energy usage. Whether you're looking to reduce reliance on the grid, store excess energy for later use, or transition to renewable energy sources, our hybrid inverters provide the solution.
Seamless Integration:
Experience seamless integration with your existing energy infrastructure. CTECHI's hybrid inverters are designed for easy installation and compatibility with a range of renewable energy sources, including solar panels and wind turbines. Upgrade your energy system with minimal hassle and maximum impact.
Reliability Guaranteed:
Backed by CTECHI's commitment to quality and durability, our three-phase hybrid inverters are built to last. With robust construction and advanced technology, you can trust in the reliability and performance of our inverters for years to come.
Take the next step towards energy independence with CTECHI's Three Phases Wall-Mounted Hybrid Inverter. Elevate your home or business with reliable, efficient, and sustainable energy solutions.
Model | WH6KL3 | WH8KL3 | WH10KL3 | WH12KL3 | WH15KL3 |
DC Input | |||||
Max.PV input power (kW) | 9 | 12 | 15 | 18 | 22.5 |
Max. PV voltage (V) | 1,000 | ||||
MPPT voltage range (V) | 180~850 | ||||
Full power MPPT voltage range (V) | 250~850 | 330~850 | 430~850 | 510~850 | 620~850 |
Start-up voltage (V) | 125 | ||||
Max. input current per MPPT (A) | 13/13 | ||||
Max. short-circuit current (A) | 16/16 | 16/16 | 16/16 | 16/16 | 25/25 |
Number of MPPT rackers | 2 | ||||
MPPT number/ Max. input strings number | 1/1 | ||||
Rated input voltage (V) | 700 | ||||
AC Output | |||||
Nominal output power to grid (kVA) | 6 | 8 | 10 | 12 | 15 |
Max. apparent power to grid (kVA) | 6.6 | 8.8 | 11 | 13.2 | 16.5 |
Max. apparent power from grid (kVA) | 13.2 | 17.6 | 22 | 26.4 | 33 |
Max. apparent current from grid (A) | 19.1 | 25.5 | 31.8 | 38.2 | 47.6 |
Nominal output current to grid (A) | 8.7 | 11.5 | 14.4 | 17.3 | 21.7 |
Max.output current to grid (A) | 9.5 | 12.7 | 15.9 | 19.1 | 23.8 |
Nominal grid voltage (V) | 380/400,3W+N+PE | ||||
Nominal grid frequency (Hz) | 50/60 | ||||
THDi | <3% | ||||
Battery | |||||
Max.charging /discharging Power (kW) | 6.6 | 8.8 | 11 | 13.2 | 16.5 |
Battery voltage range (V) | 125~600 | ||||
Battery working voltage range (V) | 150~550 | ||||
Max.charging /discharging current (A) | 50 | ||||
Rated.charging /discharging current (A) | 40 | ||||
Battery type | Lithium and Lead Acid Battery | ||||
EPS output | |||||
Nominal output power (kVA) | 8 | 8 | 10 | 12 | 15 |
Max. apparent power (kVA) | 8.8 | 8.8 | 11 | 13.2 | 16.5 |
Nominal output current (A) | 8.7 | 11.5 | 14.4 | 17.3 | 21.7 |
Max.output current (A) | 9.5 | 12.7 | 15.9 | 19.1 | 23.8 |
Nominal output voltage (V) | 400 ,3W+N+PE | ||||
Nominal output frequency (Hz) | 50/60 | ||||
THDu | <2% | ||||
Max.efficiency | 97.9% | 97.9% | 98.2% | 98.2% | 97.6% |
Europe efficiency | 97.2% | 97.2% | 97.5% | 97.5% | 97.8% |
MPPT efficiency | 99.9% | ||||
Max.battery charge/discharge efficiency | 97.5% | 97.5% | 97.5% | 97.6% | 97.8% |
General Data | |||||
Ingress protection | IP65 | ||||
Operating temperature range (℃) | -25~60 | ||||
Relative humidity | 0~100% | ||||
Operating altitude (m) | 4,000 (>2,000 Derating) | ||||
Dimensions W*H*D (mm) | 596*566*220 | ||||
Weight (kg) | 32 | ||||
Self-consumption(W) | <20 | ||||
Cooling | Natural | ||||
Noise emission (dB) | ≤25 | ||||
EMC | IEC/EN 61000-6-1:2019, IEC/EN 61000-6-2:2019, IEC/EN 61000-6-3:2021, IEN/EN 61000-6-4:2019, IEC/EN 61000-3-2:2019/A1:2021, EN 61000-3-3:2013/A2:2021, IEC/EN 61000-3-11:2019, EN 61000-3-12:2011 | ||||
On-grid | Europe: EN 50549-1:2019/AC:2019, Poland:EN50549-1:2019/Rfg:2016/NC Rfg:2018/PTPiREE:2021, Germany: VDE-AR-N 4105:2018 /DIN VDE V 0124-100(VDE V 0124-100):2020, South Africa: NRS 097-2-1:2017 Edition 2.1, UK:G98/G99/1-6:2022, Spain:UNE217001:2020 /UNE217002:2020/NTS V2.1:2021-07, IEC61727:2004/IEC62116:2014/IEC61683:1999, Hungary:EN50549-1:2019/RFG:2016/Hungary, Italy CEI 0-21 | ||||
Safety standard | IEC/EN62109-1:2010, IEC/EN62109-2:201 | ||||
Display and communication | |||||
HMI | LCD; APP | ||||
BMS | CAN | ||||
EMS/Meter | RS485/RS485 | ||||
Supported communication interface | WIFI / GPRS |
