Product Details
BR3032 can be customized for additional processing, add solder chip terminals, insulation packaging and configuration type, the model as following: BR3032/BN, BR3032/VCN, BR3032/F2N, BR3032/GUFN. The BR3032 has a voltage of 3V and a capacity of 500mAh. It can be used in various devices in the life. We test the data of this device. Here are some test data presentations. From the Operating voltage vs. load resistance chart below, you can see the state of the battery voltage at 50% of the battery under different load and temperature conditions. When the load is at 0.1MΩ, the battery voltage is 3.05V when the ambient temperature is 60°C, the battery voltage is 2.85V when the ambient temperature is 20°C, and the battery voltage is 2.76V when the ambient temperature is -10°C. When the load is at 1MΩ, the battery voltage is 3.18V when the ambient temperature is 60°C, the battery voltage is 2.98V when the ambient temperature is 20°C, and the battery voltage is 2.84V when the ambient temperature is at -10°C. When the load is at 10MΩ, the battery voltage is 3.3V when the ambient temperature is 60°C, the battery voltage is 3.1V when the ambient temperature is 20°C, and the battery voltage is 2.98V when the ambient temperature is at -10°C.
  • high quality panasonic lithium battery 3v personalized for flashlight 3
    3V 500mAh BR3032 Poly-carbon monofluoride Lithium Batteries for Panasonic Capacity vs Load Resistance
  • high quality panasonic lithium battery 3v personalized for flashlight 4
    3V 500mAh BR3032 Poly-carbon monofluoride Lithium Batteries for Panasonic Dimensions
  • high quality panasonic lithium battery 3v personalized for flashlight 5
    BR3032 3V 500mAh Poly-carbon monofluoride Lithium Batteries for Panasonic Temperature Characteristics
  • high quality panasonic lithium battery 3v personalized for flashlight 6
    Poly-carbon monofluoride Lithium Batteries BR3032 3V 500mAh for Panasonic Operating voltage vs Load Resistance
Application Scope
BR3032 3V 500mAh Poly-carbon monofluoride Lithium Batteries main feature is Super wide working temp: -40-125℃. Excellent performance in leak-proof, special seal technology, leakage can be avoided even in high temperature. Excellent perfoemance in low temperature, special high-activity material in low-temp, electrical energy can be released even in extreme low-temp. Excellent performance in high-speed movement, it can be used under 2000G(Equivalent to the car in 300km/h speed) movement. Can be used in Car Electron: Tire Pressure Monitor System (TPMS). Memorizer and back up power: Memory Back up, Clock power, Data back-up power. Various kinds of instrument panels: Intelligentized electricity meter, Water meter, Gas meter, Heat meter etc. Long-distance monitor system: Ocean telemetering system, location equipments etc. Military Applications: Wire-less communication, Night-vision devices, Tracking & Locating Devices etc.
  • high quality panasonic lithium battery 3v personalized for flashlight 7
    3V 500mAh BR3032 Poly-carbon monofluoride Lithium Batteries for Panasonic can be used in clock
  • high quality panasonic lithium battery 3v personalized for flashlight 8
    BR3032 3V 500mAh Poly-carbon monofluoride Lithium Batteries for Panasonic can be used in Heat meter
Product Comparison
CTECHi Group has the ability to meet different needs. Battery is available in multiple types and specifications. The quality is reliable and the price is reasonable.CTECHi Group's Battery has the following advantages over products in the same category.
  • high quality panasonic lithium battery 3v personalized for flashlight 9
    high quality panasonic lithium battery 3v personalized for flashlight 10
Company Advantages
1. With the help of talented experts, CTECHi panasonic lithium battery 3v comes in various innovative design styles.
2. The product is roomy enough. There is enough room (both width and depth) at the front of this shoe for the toes.
3. This product provides detailed information that clients will need to know, through which most of the clients will develop an idea of a brand and eventually lead to increased sales.

Other models of wide temperature battery

high quality panasonic lithium battery 3v personalized for flashlight 11


Company Features
1. CTECHi Technology Co. Ltd is gradually developing into a global enterprise that mainly specializes in the developing and producing of panasonic lithium battery technical handbook.
2. We have a professional product development team. They have much expertise in improving product performance. They effectively coordinate and implement our production with their innovative ideas.
3. Our current aim is to expand the overseas market through product innovation and competitive prices by walking in front of market trends and grasping the market opportunity. Check now! We aim to meet customer needs accurately, respond to a change flexibly and speedily and provide top-level products in the world to gain customers’ trust from Quality, Cost and Delivery perspectives. Check now! We are committed to becoming an industry standard enterprise. Check now!
