CTECHI 10KWh ESS Energy Storage System Home Solar Off Grid Energy Storage LiFePO4 Battery Back up
| Hybrid Solar Energy Storage System | ||||
| SOLAR INPUT SPECIFICATIONS | BATTERY SPECIFICATIONS | |||
| Vmax. PV | 130 V | Nominal Voltage | 48V | |
| Isc PV | 50A*2 | Voltage Range | 43.2 ~ 57.6V | |
| Max Power | 3KW * 2 | Operation Temperature | 0 ~ 50 º C | |
| GRID SPECIFICATIONS | LOAD SPECIFICATIONS | |||
| Max AC Power | 10KVA | Max AC Power | 10KVA | |
| Max AC Input current | 50A*2 | Max AC output current | 40A*2 | |
| Rated Grid Voltage | 155~272Vac | Rated Grid Voltage | 230Vac | |
| Rated Grid Freq. | 50Hz/60Hz | Rated Grid Freq. | 50Hz/60Hz | |
| Power Factor Range | -0.95~+0.95 | Power Factor Range | -0.95~+0.95 | |
| OTHER SPECIFICATIONS | COMPLIANCE SPECIFICATIONS | |||
| Battery Isolation | Isolated | Certifications | TUV. CE | |
| Protective Class | Protective Class | Shipping Classification | UN38.3 | |
| Protection Level | IP20 | MECHANICAL SPECIFICATIONS | ||
| Display | LCD | Dimensions (HxWxD) | 1000 x 650 x 600 mm | |
| Communication | RS485 + CAN + Wi-Fi | Weight | 100 kg | |
| Remote Monitor | Cloud | |||
A 10 kW off-grid solar system is designed to give 24*7 power in homes, Independent floors, Villas, offices. It is a powerful solar system that can run everything from solar.
if you want, all your power equipment such as Fans, lights, Television, Refrigerator to be running on solar without using grid electricity, This solar system suites to you.
Features of our home energy storage system:
1. Self-powered mode, which can maximize the self-consumption of stored energy captured by solar panels to reduce the house’s dependence on the power grid.
2. The zero export mode, a subset of the self-powered mode, can prevent any solar energy from being transferred to the grid, allowing homeowners to reduce their dependence on the grid, and maintain compliance in states that prohibit solar energy output.
3. The use time function can help homeowners living in areas where the time use policy is used to effectively manage solar energy, and reduce or eliminate the use of power grids during peak periods through optimized timetables, thereby reducing costs
4. Clean backup mode, which stores clean solar energy in smart batteries for use when the grid is interrupted. The load transfer is instantaneous and only takes 1/60 second.
5. Priority backup mode, this mode uses the full capacity of the system to charge the smart battery from the grid, so that the homeowner can prepare for the expected grid outage, such as in an upcoming storm.
6. The dark start function enables the smart battery to be debugged without the need for a power grid, and if the battery runs out of stored energy, it will only be restarted using solar energy; compared with other solar storage systems, other solar storage systems require on-site service from technicians Start a broken battery quickly.
PAY ATTENTION:
Battery module quantity for system: 30Kwh.
Battery module information : 48V50Ah, 100Ah, 150Ah. Can be configured up to 30KWh
As per customer required.
Market application of home energy storage system:
* Suitable for ordinary household electricity demand: energy saving, peak shaving.
* Suitable for energy shortage areas and eases the pressure on the power grid.
* Suitable for use in areas where natural disasters occur frequently, as a disaster emergency power supply.
* Suitable for power supply in unstable or off-grid areas.
* Suitable for power supply in non-electric areas such as border posts.
* Suitable for scenarios that require high reliability of the power grid: data center, computer room, communication backup power.
