CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell 1

CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell 2

CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell 3

CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell 4

CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell 5

CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell

Origin:

CHINA GUANGDONG

Package:

Industrial Package

Certificate:

CE/RoHS/UN38.3/MSDS

Warranty:

1 Years

MOQ:

100pieces

Payment:

Paypal/TT/Western Union/LC/DA/DP

Inquiry

Write a Review

Brand

Maxell

Weight

4.1

Item

3V 350mAh Lithium Primary Coin Battery CR2050HR

Voltage Nominal

Capacity Nominal

350mAh

Energy

1050Wh

Dimension

20*5.0mm

Charge

Operating Temperature

-40～+125℃

Product Details

The basic parameters of this CR2050HR battery are as follows: 3V350mAh, size 20*5.0mm, temperature is -40~125°C. From the temperature characteristics below you can see how the battery operates at the same load and at different temperatures. When used at an ambient temperature of 20 ° C, the voltage is 3.0 V, the voltage gradually decreases with the use of time, after 300 h, the voltage is 2.8 V, after 600 h, the voltage drops slightly to 2.6 V, after 700 h, the voltage is used At 2.4V, and continue to decline until about 720h, we can see that the battery is used for a longer period of time at room temperature. When used at an ambient temperature of 80 ° C, the voltage is 3.1V, the voltage gradually decreases with the use of time, after 300h, the voltage drops to 3.0V, after 600h, the voltage slowly drops 2.8V and continues to decline until 680h end. When used at an ambient temperature of 125 ° C, the voltage is 3.2V, the voltage gradually decreases with the use of time, after 300h, the voltage drops to 3.0V, after 500h, the voltage slowly drops 2.8V and continues to decline until 545h at the end, we can see how long the battery lasts for a long time at high temperatures.

3V 350mAh CR2050HR High Temperature Coin Cell for TPMS Maxell Dimensions
CR2050HR High Temperature Coin Cell 3V 350mAh Pulse Discharge Characteristics
CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell Discharging Characteristics
CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell Temperature Characteristics
High Temperature CR2050HR Coin Cell 3V 350mAh Relationship between Discharge Current and Discharge Capacity

Application Scope

CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell can be used in various of application, like: Tire Pressure Monitor System (TPMS). Clock power, Data back-up power. SMOKE Alertor, Temperature sensor etc. Electronical charging system etc.

CR2050HR High Temperature Coin Cell 3V 350mAh Smart water meter
CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell GPS locator

Other models of wide temperature battery

CR2050HR High Temperature Coin Cell 3V 350mAh for TPMS Maxell 13

Maxell CR2050HR: The high-performance coin cell battery built to endure extreme temperatures. Never worry about unreliable tire pressure readings again. Replace your car's TPMS (Tire Pressure Monitoring System) battery with the Maxell CR2050HR and experience long-lasting performance in all weather conditions.

This 3V lithium coin cell battery boasts a remarkable 350mAh capacity, delivering extended battery life for your TPMS sensor. Maxell's high-quality construction ensures excellent anti-leakage protection for safe and reliable use.

Here are some of the key benefits of Maxell CR2050HR:

High-Temperature Resistance: Functions flawlessly in extreme weather, from -40°C to +125°C (depending on conditions).
Long-Lasting Performance: 350mAh capacity ensures extended battery life for your TPMS sensor.
Reliable Performance: Maxell's trusted quality delivers consistent and dependable power.
Excellent Anti-Leakage Protection: Safeguards against potential damage from leaks.
Wide Range of Applications: Suitable for various devices beyond TPMS, such as car clocks, key fobs, and more.

Ensure peace of mind on the road with the Maxell CR2050HR high-temperature coin cell battery.
