CTECHI is an expert in battery solutions, specializing in ODM, OEM, and SKD for energy storage, motive power, and consumer batteries.

3090mah iPhone battery factory for store 1
3090mah iPhone battery factory for store 2
3090mah iPhone battery factory for store 3
3090mah iPhone battery factory for store 1
3090mah iPhone battery factory for store 2
3090mah iPhone battery factory for store 3

3090mah iPhone battery factory for store

Inquiry
Video Display
Product Details
3.8V 3090mAh Cell for Phone 6SP, 6P. and about the cell information as following: About Shock Test, The Cell is to be secured to the testing machine by means of a rigid mount which supports all mounting surfaces of the Cell. Each Cell shall be subjected to a total of three shocks of equal magnitude. The shocks are to be applied in each of three mutually perpendicular directions unless it has only two axes of symmetry in which case only two directions shall be tested. Each shock is to be applied in a direction normal to the face of the Cell. For each shock the Cell is to be accelerated in such a manner that during the initial 3milliseconds the minimum average acceleration is 75g (where g is the local acceleration due to gravity).The peak acceleration shall be between 125and175g. Cells shall be tested at a temperature of 20±5°C (68±9°F). About Forced-Discharge. A fully discharged Cell is to be force-discharged by connecting it in series with fully charged Cells of the same kind. The number of fully charged Cells to be connected in series with the discharged Cell is to equal the maximum number less one of the Cells to be covered for series use. Five Cells are to be fully discharged, at room temperature. Once the fully discharged Cell is connected in series with the specified number of fully charged Cells the resultant battery pack is to be short circuited. The positive and negative terminals of the sample are to be connected with a resistance load of 80±20mΩ. The sample is to discharge until a fire or explosion is obtained,or until it has reached a completely discharged state of less than 0.2 V and the battery case temperature has returned to ±10℃ of ambient temperature. The voltage at the end of the test may not reach 0.2 V due to operation of protective devices in the circuit. The return to near ambient of the Cell casing is an indication of ultimate results.
  • 3090mah iPhone battery factory for store 4
    CTECHI 38V 3090mAh Battery Fit for Phone 6SP Cell Size
  • 3090mah iPhone battery factory for store 5
    CTECHI 3449B9 38V 3090mAh Battery for Phone 6SP
  • 3090mah iPhone battery factory for store 6
    CTECHI OEM Phone Battery 38V Replacement Fit for Phone
Application Scope
Grade AAA Original Quality Cell Phone 3.8V 3090mAh Battery can used in Phone 6P and Phone 6SP, the PCM is not same. Please contact with us, if you need different types, we can also provide other brand phone battery.
  • 3090mah iPhone battery factory for store 7
    CTECHI 38V 3090mAh Battery Can be used in Phone 6SP
  • 3090mah iPhone battery factory for store 8
    CTECHI OEM Phone Battery for Battery Replacement 38V 3090mAh for Phone 6SP
iPhone battery description
Performance and advantages of iPhone battery: iPhone 6 plus battery. It is always showcased at exhibitions such as Hong Kong Electronics Fair
3090mah iPhone battery factory for store
3090mah iPhone battery factory for store
iPhone battery SPECIFICATIONS
OriginCHINA GUANGDONG
PackageIndustrial Package
CertificateCE/RoHS/UN38.5/MSDS
Warranty3 Years
ColorCustomized Available
MOQ1000pieces
PaymentL/C, D/A, D/P, T/T, Western Union
BrandCTECHI
Weight44g
ItemCTECHI 3.8V 3090mAh Battery for Phone 6SP and 6P
Voltage Nominal3.8V
Capacity Nominal3090mAh
Energy11.74Wh
Dimension3.3*48.7*119mm
ChargeYes
Operating Temperature-20~-10℃ 0.35Cmin Max to 3.0 V-10~0℃ 0.5Cmin Max to 3.0 V0~60℃ 0.7Cmin Max to 3.0 V
It is manufactured in high efficiency which is backed by 13+ year experience. Its research and development is carried out by 3 companies combined to be CTECHi Group. It is CE/ISO/ROHS/UN38.3/MSDS/UL certified.
Suggested Videos
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
