Product Details
The internal structure of LiFePO4 battery: LiFePO4 with olivine structure on the left is used as the positive electrode of the battery. The aluminum foil is connected with the positive electrode of the battery. The middle is the separator of the polymer. It separates the positive electrode from the negative electrode, but the lithium ion Li+ can pass and the electron e- Can not pass, the right side is a battery negative electrode composed of carbon (graphite), connected by copper foil to the negative electrode of the battery. Between the upper and lower ends of the battery is the electrolyte of the battery, and the battery is hermetically sealed by a metal casing.
When the LiFePO4 battery is charged, the lithium ion Li+ in the positive electrode migrates toward the negative electrode through the polymer separator; during the discharge, the lithium ion Li+ in the negative electrode migrates toward the positive electrode through the separator. Lithium-ion batteries are named after the lithium ions migrate back and forth during charging and discharging.
The nominal voltage of the LiFePO4 battery is 3.2 V, the termination charging voltage is 3.6 V, and the termination discharge voltage is 2.0 V. Due to the quality and process of the positive and negative materials and electrolyte materials used by various manufacturers, there will be some differences in their performance. For example, the same model (standard battery of the same package) has a large difference in battery capacity (10% to 20%).
-
32V 280Ah Rechargeable LiFePO4 Battery Size
-
C-Rate Curve of Deep Cycle Life LiFePO4 Cell 32V 280Ah for Electric Truck
-
Deep Cycle Life LiFePO4 Cell 32V 280Ah Cycle Performance Curve
-
LiFePO4 Cell 32V 280Ah Different Temperature Discharge Curve
Application Scope
Deep Cycle Life LiFePO4 Cell 3.2V 280Ah main application is Solar Energy Storage System, UPS, EV, Electric Truck, Golf Cart and so on. It is also the best choice for replacing lead-acid batteries.
-
Deep Cycle Life LiFePO4 Cell 32V 280Ah for Boat
-
Deep Cycle Life LiFePO4 Cell 32V 280Ah for UPS
-
Deep Cycle Life LiFePO4 Cell 32V 280Ah for Wind Storage System (1)
Application Scope
Battery developed and produced by CTECHi Group is widely applied to many industries and fields. It can fully meet the diversified needs of customers.With many years of practical experience, CTECHi Group is capable of providing comprehensive and efficient one-stop solutions.
Company Advantages1. When producing CTECHi 6v lifepo4 battery , our personnel makes use of advanced production techniques.
2. The product is carefully tested by professional QC staff in all respects, including durability, performance, etc.
3. People don't have to worry that this product will suffer from aging issues and it can run in harsh conditions.
4. For people who never want to be without power, this product provides them with the convenience and reliability to keep their devices on.
Company Features1. Well known to the market for 6v lifepo4 battery developing and manufacturing advantages, CTECHi Technology Co. Ltd is highly recognized and respected in the market.
2. Numbers of members of CTECHi Technology Co. Ltd have long-term experience in R&D and operation of what is lifepo4 battery .
3. Our goal is to provide clients with the best product solution and help their businesses grow. We attach importance to clients' problems and requirements and develop a strong and effective solution that works perfectly in their markets. Please contact. We deliver our value proposition in several areas through innovation, rationalization, optimization, and automation enabled by our people, products and services. We understand that giving back is what drives us to success. We encourage employees to donate time, energy, or money to their communities, such as cleaning up parks or volunteering at homeless shelters. Please contact.
